Flowlines supplies CCTV Poles engineered for public security, traffic monitoring, and perimeter protection. These poles are designed with concealed cable management, durable coatings, and robust steel construction to ensure long service life and compliance with Qatar Standards (QCS2014) and international specifications such as ASTM A123/A123M and BS EN ISO 1461:2009.

With hot‑dip galvanization (80–100 microns) and powder/epoxy coatings (100–150 microns), the poles provide maximum weather protection and low maintenance requirements. Decorative aluminium cladding with reflective coating can be added if required, making them suitable for both functional and aesthetic applications.

Product Features

• Cable management: Concealed structure for secure wiring

• Finish: Epoxy paint or powder coat as per Qatar Standard

• Cladding: Aluminium decorative cladding with optional reflective coating

• Galvanization: Hot‑dip galvanization, 80–100 microns (ASTM A123/A123M, BS EN ISO 1461:2009)

• Coating thickness: Powder/epoxy coating, 100–150 microns for weather protection

• Locking system: Solid steel door lock with provision for tamper switches

• Steel grade: ASTM A53, BSEN 10025 S275JR

• Accessories: Access door with Allen key bolt, stiffener plate welded to pole, top end cap (2–3 mm thick)

• Base plate: MS/CS plate/sheet sized according to pole shaft diameter

• Finish options: HDG powder coated or epoxy painted

• Welding standards: AWS D.1, D1.1M

• Welding process: GMAW/MIG
